Description:
General Information
Manufacturer: Advantech Co., Ltd
Manufacturer Part Number: 232HESP
Brand Name: B+B SmartWorx
Product Model: 232HESP
Product Name: RS-232 High Energy Surge Protector
Marketing Information: The Model 232HESP is designed to help protect against lightning strikes, power surges, and other types of voltage disturbances. Five RS-232 signals on terminal blocks are supported with a clamping voltage of approximately 15 volts. The 232HESP offers three stages of protection starting with a gas discharge tube followed by a series resistor and finally a Transient Voltage Suppresser (TVS). In order for a surge protector to work properly it is important to have a good connection to earth ground. The 232HESP offers two terminal posts and two metal mounting brackets that provide a good ground connection for the user. The 232HESP has been tested to two specifications at 6 kilovolts, IEC 1000-4-5: 1995 "Surge Immunity Test" and IEEE C62.41-1991 "IEEE Recommended Practice on Surge Voltages in Low-Voltage AC Power Circuits". To ensure the best protection of your equipment some simple connection guidelines should be followed.
Product Type: Surge Suppressor/Protector
Technical Information
Receptacles: Terminal Block
Physical Characteristics
Height: 1.80" (45.72 mm)
Width: 3.30" (83.82 mm)
Depth: 4.50" (114.30 mm)
Weight (Approximate): 6.70 oz (189.94 g)
Miscellaneous
Country of Origin: United States
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty: Lifetime
