Description:
General Information
Manufacturer: Lenovo Group Limited
Manufacturer Part Number: 4XB7A17119
Brand Name: Lenovo
Product Series: S4520
Product Name: ThinkSystem 3.5" S4520 480GB Read Intensive SATA 6Gb HS SSD
Marketing Information:
The ThinkSystem S4520 Read Intensive SATA SSDs use 144-layer Intel 3D NAND TLC Flash Memory technology with a 6Gbps SATA interface to provide an affordable solution with industry leading performance.
Compared with the S4510 series, these new Read Intensive (Entry) drives offer improved endurance. The S4520 SSDs are optimized for read-intensive applications such as boot, web servers, lower data rate operational databases and analytics.
Product Type: Solid State Drive
Technical Information
Storage Capacity: 480 GB
Encryption Standard: 256-bit AES
Drive Performance
Maximum Read Transfer Rate: 563200 MB/s
Maximum Write Transfer Rate: 471040 MB/s
Random 4KB Read: 79000IOPS
Random 4KB Write: 30000IOPS
Endurance (DWPD): 2.8
Endurance (TBW): 2560 TB
Endurance Type: Read Intensive
Network & Communication
Wireless LAN: No
Interfaces/Ports
Drive Interface: SATA
Drive Interface Standard: SATA/600
Physical Characteristics
Rugged: Yes
Drive Type: Internal
Form Factor: 3.5"
Hot Swappable: Yes
Height: 0.28" (7 mm)
Width: 2.76" (70 mm)
Depth: 3.94" (100 mm)
Weight (Approximate): 2.47 oz (70 g)
Miscellaneous
Device Supported: Server
Compatibility:
ThinkSystem Servers:
- ST250 V2 (7D8G / 7D8F)
- SR250 V2 (7D7R / 7D7Q)
Environmentally Friendly: Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)Waste Electrical and Electronic Equipment Directive (WEEE) Warranty
Limited Warranty: 1 Year
Additional Warranty Information: The S4520 SSDs carry a one-year, customer-replaceable unit (CRU) limited warranty.
