Description:
General Information
Manufacturer: Shuttle, Inc
Manufacturer Part Number: DH610
Brand Name: Shuttle
Product Line: XPC slim
Product Model: DH610
Product Name: XPC slim DH610 Barebone System
Marketing Information:
Robust 1.3-litre Slim PC supports Intel Core Gen. 12 processors "Alder Lake-S" and two UHD displays
The Shuttle XPC slim Barebone DH610 with H610 chipset houses the performance of Intel's 12th generation Core desktop processors (codenamed Alder Lake-S) for socket LGA1700 in a compact 1.3-litre format. The DH610 allows for three Ultra HD displays to be operated at the same time via 1x HDMI and 2x DisplayPort. It also offers Dual Intel LAN (one supports 2.5G speed), eight USB ports and two COM ports. The slim metal chassis comes with a VESA mount included, provides versatile connectivity and reliable operation in environments with ambient temperatures of up to 50 °C. This platform is targeted at professional applications such as Digital Signage, POS, POI, gambling machines, office, healthcare and industry.
Product Type: Barebone System
Processor
Number of Processors Supported: 1
Processor Socket: Socket LGA-1700
Processor Supported: Core i9Core i7Core i5Core i3Pentium GoldCeleronChipset
Chipset Manufacturer: Intel
Chipset Model: H610
Memory
Maximum Memory Supported: 64 GB
Memory Technology: DDR4 SDRAM
Memory Standard: DDR4-3200/PC4-25600
Total Number of Memory Slots: 2
Controllers
Controller Type: Serial ATA/600
Display & Graphics
Graphics Controller Model: HD Graphics
Graphics Memory Technology: DDR4 SDRAM
Graphics Memory Accessibility: Shared
Network & Communication
Ethernet Technology: 2.5 Gigabit EthernetGigabit EthernetI/O Expansions
Number of Total Expansion Bays: 1
Interfaces/Ports
HDMI (Rear): Yes
Total Number of USB Ports: 8
Number of USB 3.2 Gen 1 Ports: 3
USB Type-C (Front): Yes
USB Type-C Detail: 1 x USB 3.2 Gen 1 Type-C
Operating System
Operating System Supported: Windows 10 x64Windows 11 x64LinuxPower Description
Input Voltage: 120 V AC230 V ACMaximum Power Supply Wattage: 120 W
Physical Characteristics
Color Family: Black
Product Color: Black
Form Factor: Slim PC
Height: 1.69" (43 mm)
Width: 6.50" (165 mm)
Depth: 7.48" (190 mm)
Weight (Approximate): 2.87 lb (1300 g)
Miscellaneous
Package Contents:
- XPC slim DH610 Barebone System
- Multi-Language User Guide (EN, DE, FR, ES, JP, KR, SC, TC)
- VESA Mount For 75/100 mm Standard (two metal brackets)
- 4 x Screws M3 x 5 mm (screws together VESA mount and PC)
- 4 x Screws M4 x 10 mm (to affix VESA mount on the PC)
- 4 x Screws M3 x 4 mm (to mount a 2.5" storage device into the bay)
- 2 x Screws M3 x 5 mm (silver colour, to mount two M.2 cards)
- Driver DVD (Windows 64-bit)
- Serial ATA Cable For 2.5" Drive Including Power Cable
- External 120 W Power Adapter With Power Cord
- Protection Cap For CPU Socket (do not use if heatpipe or fan is mounted)
- Heatsink Compound
Energy Star: Yes
Environmentally Friendly: Yes
Energy Efficiency Compliance: Energy-related Products Directive (ErP)
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
