Description:
General Information
Manufacturer: Honeywell International, Inc
Manufacturer Part Number: 1962HHD5USB5N
Brand Name: Honeywell
Product Line: Xenon Ultra
Product Model: 1962h
Product Name: Xenon Ultra 1962H Barcode Scanner Kit
Marketing Information:
Continuing the legacy of barcode technology, Honeywell's Xenon Ultra helps to ensure clinicians are delivering fast, accurate and reliable patient care.
The Xenon Ultra 1962h incorporates Honeywell's next generation of scanning capability- allowing patient care to stay top priority for clinicians, helping improve retention of employees and helping lower the total cost of ownership for hospitals.
Developed with the healthcare environment in mind, the Xenon Ultra offers an improved design which reduces the amount of nooks or crannies, helping to limit areas where germs could linger and hide.
Freedom of movement around patients, family members, and expensive equipment - particularly in congested patient rooms or ICUs - is a continued challenge for today's clinician. As more and more technology is packed into the modern-day patient room, free space comes at a premium. The Xenon Ultra 1962h scanner takes up minimal space, can be mounted or stored in a variety of different places, ensuring nurses' focus is on patient safety and comfort. One scanner can now accept multiple power sources. Available with a battery-free supercapacitor or standard lithium-ion battery, both power options are also available in contactless orientations.
The battery-free technology runs on supercapacitors versus a battery and is capable of achieving a full charge in less than four minutes via the USB Port (under 60 seconds when using a powered USB port or external wall adapter). The Xenon Ultra 1962h scanner typically provides at least 450 scans of UPC/EAN Codes without recharging. This makes the scanner ideal for scanning applications at the bedside such as medicines administration or specimen collection.
Product Type: Barcode Scanner Kit
Technical Information
Connectivity Technology: Wireless
Scanning Capability:
1D2DBarcode Symbology Supported:
Decode Capabilities:
- Reads standard 1D, PDF, 2D, Postal Digimarc, DOT Code, and OCR symbologies
Light Source: LED
Field of View (Horizontal): 42°
Field of View (Vertical): 36°
Reading Angle (Skew): 65°
Reading Angle (Pitch): 65°
Reading Angle (Roll): 360°
Maximum Ambient Light: 100000 lux
Drop Specification:
Engineered to withstand 50 drops at 1.8 m (6 ft) to concrete across operating temp range
Minimum Print Contrast: 15%
Minimum Element Resolution (Code 39): 3 mil (0.08 mm)
Maximum Element Resolution (Code 39): 20 mil (0.51 mm)
Minimum Element Resolution (DataMatrix): 5 mil (0.13 mm)
Maximum Element Resolution (DataMatrix): 10 mil (0.25 mm)
Minimum Element Resolution (PDF417): 5 mil (0.13 mm)
Maximum Element Resolution (PDF417): 6.70 mil (0.17 mm)
Image Sensor Resolution: 1280 x 1080
Illumination Type: LED
Illumination Color: White
Network & Communication
Bluetooth: Yes
Radio Frequency: Yes
Interfaces/Ports
Host Interface: USB
Power Description
Maximum Operating Power Consumption: 2.50 W
Input Current: 500 mA
Battery Information
Battery Chemistry: Lithium Ion (Li-Ion)
Battery Capacity: 3300 mAh
Maximum Battery Run Time: 22 Hour
Maximum Battery Recharge Time: 4.50 Hour
Environmental Conditions
Operating Temperature: 41°F (5°C) to 95°F (35°C)
Storage Temperature: -40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing): 0% to 95%
Physical Characteristics
Form Factor: Handheld
Product Color: White
Height: 4.80" (121.92 mm)
Width: 3.60" (91.44 mm)
Length: 3.30" (83.82 mm)
Weight (Approximate): 7.76 oz (220 g)
Miscellaneous
Ingress Protection (IP) Rating: IP52IP41Application/Usage: Healthcare
Warranty
Limited Warranty: 3 Year
