General Information

---

Manufacturer: ViewSonic Corporation
Manufacturer Part Number: TD3207
Brand Name: ViewSonic
Product Model: TD3207
Product Name: TD3207 32" LCD FHD Touch Screen Monitor (HDMI, DisplayPort)
Marketing Information: The e+Box® II Mobile Stand is a motorized mobile stand for interactive and non-interactive displays. It has a double-column design that guarantees stability for interactive display up to 98" diagonal with a 309 lbs (140 kg) total weight capacity. The wired remote control unit can be placed at a convenient location, allowing the user to adjust the height of the screen safely and quietly. The motorized stand has a dual anti-collision safety feature to prevent accidental pinching. The 25.6" travel will guarantee full screen access for all users, which makes the interactive display mounting solution ideal for small, tall or wheelchair users.

More from the Manufacturer

Packaged Quantity: 1
Product Type: Open-frame LED Touchscreen Monitor

Technical Information

---

Screen Size Class: 32"
Viewable Screen Size: 31.5"
Screen Mode: Full HD
Panel Technology: In-plane Switching (IPS) Technology
Response Time: 5 ms
Aspect Ratio: 16:9
Horizontal Viewing Angle: 178°
Vertical Viewing Angle: 178°
Backlight Technology: LED
Features:

Anti-glare

On-screen Display (OSD)

Anti-Burn-in Technology

Horizontal Frequency:

15 kHz to 73 kHz - HDMI 1.4

15 kHz to 73 kHz - DisplayPort

Vertical Frequency:

47 Hz to 75 Hz - HDMI 1.4

47 Hz to 75 Hz - DisplayPort

Operation Hours: 24 Hours/7 Days
Ingress Protection (IP) Rating: IP54
Glass Hardness:

3H

7H

Video

---

Maximum Resolution: 1920 x 1080
Color Supported: 16.7 Million Colors
Native Contrast Ratio: 3,000:1
Dynamic Contrast Ratio: 50,000,000:1
Brightness: 450 cd/m²

Audio

---

Speakers: Yes

Touchscreen Information

---

Touchscreen Type: Projected Capacitive
Multi-touch Screen: Yes
Number of Simultaneous Touchpoints: 10

Interfaces/Ports

---

HDMI: Yes
USB: Yes
DisplayPort: Yes
Number of HDMI Inputs: 1
Total Number of HDMI Ports: 1
Number of DisplayPorts: 1
Number of USB Ports: 1
Number of USB Type-B Ports: 1

Environmental Conditions

---

Operating Temperature Range: 32°F (0°C) to 104°F (40°C)
Operating Humidity Range: 20% to 90% (Non-condensing)

Power Description

---

Operating Power Consumption: 50 W
Maximum Power Consumption: 50 W

Physical Characteristics

---

Color Family: Black
Product Color: Black
VESA Mount Compatible: Yes
VESA Mount Standard: 400 x 200
Height with Stand: 17.76" (451 mm)
Width with Stand: 29.41" (747 mm)
Depth with Stand: 2.52" (64 mm)
Weight with Stand (Approximate): 28.22 lb (12800 g)

Miscellaneous

---

Package Contents:

• 32" 1080p Open Frame 10-Point Touch Monitor with 24/7 Operation and HDMI, DisplayPort and RS232
• Power Cable
• HDMI to HDMI Cable
• USB A to USB B Cable
• Quick Start Guide

Energy Star: Yes
Country of Origin: China
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Warranty

---

Limited Warranty: 3 Year
